Mac Studio M4 Thunderbolt cable comb
A comb that sits on the rear I/O of a Mac Studio M4 and separates four Thunderbolt 5 cables plus HDMI so they unplug one at a time. The body is 180 × 22 × 18 mm with five saddles (8 mm × 4 and 14 mm HDMI) and two 3 mm lips that hook the Studio's rear lip. Print in PETG with 2 mm walls. Open the ready-made model free, resize it on your phone or computer, then download a print-ready STL, 3MF or G-code sliced for your printer, free.Opening the ready-made model and downloading it as STL or 3MF are free, no card; AI changes use credits, from Maker at $7.99 a month.No printer? We print this part and ship it to your door. See its priceUpdated
2
Adjust
Change its numbers in the viewer for free, or ask the AI in the chat: wall thickness, hole size, the thing it clips onto. AI changes use 2 credits per request (1 for a quick edit, 3 for a redesign), paid with a plan from Maker at $7.99 a month, where the first 3 small changes are free.3Print
Download a watertight STL or 3MF free, with your numbers and hand edits, or G-code sliced for your printer at the same price. After an AI change the download is included in every plan (4 credits without one).
Dimensions of the ready-made model (editable)
| Parameter | Value |
|---|---|
| Overall length | 180 mm |
| Overall depth | 22 mm |
| Overall height | 18 mm |
| Wall thickness (PETG) | 2 mm |
| Small cable diameter | 8 mm |
| HDMI cable diameter | 14 mm |
| Rear retention lip height | 3 mm |
| Clearance around cables | 0.3 mm |
Example prompt
Design a Mac Studio M4 Thunderbolt comb 180×22×18 mm, four 8 mm saddles plus 14 mm HDMI, two 3 mm rear lips, 2 mm PETG.
Fit notes
Cables behind a Studio become a single brick. Tell SpeakCAD how many TB ports you use, preview the comb in the browser, then download the STL.
Questions people ask about a Mac Studio M4 Thunderbolt cable comb
A comb that sits on the rear I/O of a Mac Studio M4 and separates four Thunderbolt 5 cables plus HDMI so they unplug one at a time. The body is 180 × 22 × 18 mm with five saddles (8 mm × 4 and 14 mm HDMI) and two 3 mm lips that hook the Studio's rear lip. Print in PETG with 2 mm walls.
Click Open it free on this page and create a free account (no card): the ready-made model opens in your browser, on your phone or computer, nothing to install. Change its numbers in the viewer for free and download a watertight STL or 3MF free, or G-code sliced for your printer at the same price. An AI change in the chat uses 2 credits per request (3 for a redesign), and the download after it is included in every plan (4 credits without one). Start with Maker: 50 credits a month for $7.99, cancel anytime.
On this page: open the ready-made model free in a SpeakCAD account (no card), change any dimension in the viewer, then download the STL or 3MF free, or G-code sliced for your printer at the same price.
A shared STL is modelled for someone else's measurements. Here you open the ready-made model free, change it to your measurements in the viewer, then download a file sized for the part you actually own, free as STL or 3MF.
Yes. SpeakCAD slices the part on its servers with OrcaSlicer and your printer's official profile (380+ printers, including Bambu Lab, Prusa, Creality and Elegoo), and you download the G-code (a sliced .gcode.3mf for Bambu Lab printers). G-code sliced for your printer costs the same as the STL: included in every plan, free for a part you shaped by hand, 4 credits without a plan for a part with AI work in it. Pick your printer on the printers page to see its profile.
No. SpeakCAD runs in the browser on your phone or computer: the chat, the 3D engine and the live viewer load in the tab. The only file you download is the finished STL, 3MF or sliced G-code.
