Magic Keyboard with Numeric Keypad angled tray
A 6 degree tray for the Magic Keyboard with Numeric Keypad (about 418 × 115 × 11 mm) so the larger board matches a Magic Trackpad wedge. The well is 420 × 117 mm with 0.4 mm clearance, a 14 mm USB-C slot at the back, and the plate is 430 × 130 × 20 mm. Print as two PLA halves. Open the ready-made model free, resize it on your phone or computer, then download a print-ready STL, 3MF or G-code sliced for your printer, free.Opening the ready-made model and downloading it as STL or 3MF are free, no card; AI changes use credits, from Maker at $7.99 a month.No printer? We print this part and ship it to your door. See its priceUpdated
2
Adjust
Change its numbers in the viewer for free, or ask the AI in the chat: wall thickness, hole size, the thing it clips onto. AI changes use 2 credits per request (1 for a quick edit, 3 for a redesign), paid with a plan from Maker at $7.99 a month, where the first 3 small changes are free.3Print
Download a watertight STL or 3MF free, with your numbers and hand edits, or G-code sliced for your printer at the same price. After an AI change the download is included in every plan (4 credits without one).
Dimensions of the ready-made model (editable)
| Parameter | Value |
|---|---|
| min wall / floor thickness | 1.6 mm |
| overall length | 430 mm |
| overall depth | 130 mm |
| overall thickness | 20 mm |
| outer corner radius | 5 mm |
| keyboard footprint length | 420 mm |
| keyboard footprint width | 117 mm |
| average pocket depth at well centre | 8 mm |
| clearance around keyboard | 0.3 mm |
| slot width | 14 mm |
| slot height | 5 mm |
| slot centre distance from right end | 90 mm |
| x position of the split between halves | 213 mm |
| tongue length in x | 6 mm |
Example prompt
Model a Magic Keyboard Numeric tray 430×130×20 mm, 420×117 mm well at 6 degrees, 14 mm USB-C slot, two PLA halves, 1.6 mm walls.
Fit notes
The Touch ID tray is 140 mm too short for the numeric board. In SpeakCAD you confirm Touch ID vs numeric, preview the tray in the browser, then download the STL.
Questions people ask about a Magic Keyboard with Numeric Keypad angled tray
A 6 degree tray for the Magic Keyboard with Numeric Keypad (about 418 × 115 × 11 mm) so the larger board matches a Magic Trackpad wedge. The well is 420 × 117 mm with 0.4 mm clearance, a 14 mm USB-C slot at the back, and the plate is 430 × 130 × 20 mm. Print as two PLA halves.
Click Open it free on this page and create a free account (no card): the ready-made model opens in your browser, on your phone or computer, nothing to install. Change its numbers in the viewer for free and download a watertight STL or 3MF free, or G-code sliced for your printer at the same price. An AI change in the chat uses 2 credits per request (3 for a redesign), and the download after it is included in every plan (4 credits without one). Start with Maker: 50 credits a month for $7.99, cancel anytime.
On this page: open the ready-made model free in a SpeakCAD account (no card), change any dimension in the viewer, then download the STL or 3MF free, or G-code sliced for your printer at the same price.
A shared STL is modelled for someone else's measurements. Here you open the ready-made model free, change it to your measurements in the viewer, then download a file sized for the part you actually own, free as STL or 3MF.
Yes. SpeakCAD slices the part on its servers with OrcaSlicer and your printer's official profile (380+ printers, including Bambu Lab, Prusa, Creality and Elegoo), and you download the G-code (a sliced .gcode.3mf for Bambu Lab printers). G-code sliced for your printer costs the same as the STL: included in every plan, free for a part you shaped by hand, 4 credits without a plan for a part with AI work in it. Pick your printer on the printers page to see its profile.
No. SpeakCAD runs in the browser on your phone or computer: the chat, the 3D engine and the live viewer load in the tab. The only file you download is the finished STL, 3MF or sliced G-code.
